Induction Loop Cleanroom SIP Elevator Emergency Phone

Product Details

Place of Origin: Shenzhen, China

Brand Name: J&R

Certification: CE, FCC, RoHS, ISO9001

Model Number: JR303-SC

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Reconsideration

Packaging Details: pearl cotton, carton

Delivery Time: 2-5 working days

Payment Terms: L/C, T/T

Supply Ability: 3000 sets per month

Get Best Price
Product Details
High Light:

Induction Loop Elevator Intercom Phones

,

SIP Lift Emergency Phone

Material:
Stainless Steel
Customized Unit:
Support
Warranty:
2 Years
Weather Protection:
IP55-IP65
Version:
Analog, SIP, GSM/3G
Installation:
In Wall Mounted
Unit Size:
300 *220 *50 (mm)
Weight:
2.5 KG
Material:
Stainless Steel
Customized Unit:
Support
Warranty:
2 Years
Weather Protection:
IP55-IP65
Version:
Analog, SIP, GSM/3G
Installation:
In Wall Mounted
Unit Size:
300 *220 *50 (mm)
Weight:
2.5 KG
Product Description





Product Description



JR303-SC-IW Waterproof Cleanroom Telephone with Induction Loop



JR303-SC Waterproof Cleanroom Telephone with Induction Loop was designed specifically for use in clean rooms, pharmaceutical rooms and laboratories.

The push button and loudspeaker are arranges on a level surface and are easy to clean.

Humanistic care design, built-in induction loop system, offering larger convenience to more people.



  Casing Material

Cold rolled steel back cover with stainless steel faceplate

  Handset Material

No Handset(hands free operation)

  Keypad

No Keypad

  Antenna

Quad-band SMA male, external mounted with 2M cable

  Operating temperature

(AC powered) -20°C to +60°C

(Battery powered, lead-acid) -20°C to +60°C

  Weather Resistance

IP65-IP66

  Ringing Tone

Shrill warble tone 80 dBA @ 1 metre typical

  Hooks witch

No Hook switch

  M.T.B.F.

Calculated to have an M.T.B.F. in excess of 50,000 hours

















Technical Specification



Waterproof Cleanroom Telephone with Induction Loop

Induction Loop Cleanroom SIP Elevator Emergency Phone 1





  Analogue Version
   Power Supply From the analogue telephone network
   Supply Voltage 24 VDC to 65 VDC
   Supply Current 20 mA DC to 100 mA DC
   Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
   Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.



  SIP Version
   Power Supply PoE or 12V DC
   Power Consumption -Idle:1.5W
-Active:1.8W
   SIP Protocol SIP 2.0 (RFC3261)
   Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
   Communication Type Full duplex
   Ringer volume - 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)



  Ambient conditions
   Protection type IP 66 as per EN60529
   Operating temperature -40°C to +70°C
   Storage temperature -45°C to +85°C











Applications



Waterproof Cleanroom Telephone with Induction Loop

Induction Loop Cleanroom SIP Elevator Emergency Phone 2















Features



Waterproof Cleanroom Telephone with Induction Loop

Induction Loop Cleanroom SIP Elevator Emergency Phone 3

Standard Analogue,SIP or GSM phone



Robust housing, constructed of stainless steel



Vandal resistant metal buttons



Hands free operation, One call button



In wall mounting, simple installation



Weather proof protection: up to IP55



Phone line powered(Analog)



​ External power supply or PoE (SIP)











Packing & Delivery



Waterproof Cleanroom Telephone with Induction Loop

Induction Loop Cleanroom SIP Elevator Emergency Phone 4
Unit Size 300 *220 *50 (mm)
Carton Size 340 *235 *165 (mm)
Packaging Materials Pearl cotton, carton
Net Weight 2.5 KG
Gross Weight 3 KG



Port Shenzhen, Guangdong
Lead Time
(If you finish the payment today, your order will ship out within the delivery date.)
Quantity(Sets) 1 2-500 >500
Est. Time(Days) 2 25 To be negotiated











Our Company



Waterproof Cleanroom Telephone with Induction Loop

Induction Loop Cleanroom SIP Elevator Emergency Phone 5

J&R Technology The company has long-term cooperated with many well-known international companies to steadily promote product development and innovation. The telephones like industrial telephones, weatherproof telephones and explosion-proof telephones and many other products are adopted by large mines, municipal projects and outdoor scenic spots.
