| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | J&R |
| Certification: | CE, FCC, RoHS, ISO9001 |
| Model Number: | JR101-CB |
| Minimum Order Quantity: | 1 |
| Price: | Reconsideration |
| Packaging Details: | Pearl cotton, Carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000 sets per month |
| Product Name: | Anti Vandal Industrial VOIP Phone Weatherproof IP67 Hotline Telephone For Truck | Material: | Aluminum Alloy |
|---|---|---|---|
| Color: | Yellow,Blue, Red | Package: | Pearl Cotton, Carton |
| Modle: | Analog/ SIP/ GSM/ 3G | Mounting: | Wall /Pillar Mounted |
| Ingress Protection Rating: | IP66-IP67 | Full Keypad: | No |
| Door Cover: | Yes | Feature: | Hot Line |
| Handset: | Yes | Temperature: | -30°C To +65°C |
| OEM: | Yes | Warranty: | 2 Years |
| High Light: | rugged voip phone,voice over ip phone |
||
Product Description
As a weatherproof telephone, it is fully contained within a corrosion resistant cast aluminium weatherproof case with a door.
The unique robust handset is manufacture from moulded Bulk Molding Compound and designed specifically to withstand arduous use in all environments, armoured cord to provide additional resistance to vandalism or heavy industry use.
Anti Vandal Industrial VOIP Phone Weatherproof IP67 Hotline Telephone for Truck
Specification
Power Input:12-24V DC
Port: WAN: 10/100Base- T RJ-45 for LAN, Auto MDIX
LAN: 10/100Base- T RJ-45 for PC, Auto MDIX
Power Consumption:Idle:1.5W/ Active:1.8W
Voice Features
Support SIP 2.0 (RFC3261)
Codec: G.711A/u, G.7231 high/low, G.729, G.722
Echo cancellation: Support G.168 and hand-free can support 96ms
Supports full duplex
SIP support SIP domain, SIP authentication(none, basic,MD5),DNS name of server
DTMF:SIP info, DTMF Relay,RFC2833
Call control features: Flexible dial map, support hot-line
Network Features
WAN/LAN: support Bridge mode
Support static IP address
Support DHCP get IP on WAN port
Support VLAN
Support web config
Application
Ideal for public place outdoor or somewhere dusty, full of corrosive gases. For example, bank, park, station, railway, power stations, heavy industry.
Anti Vandal Industrial VOIP Phone Weatherproof IP67 Hotline Telephone for Truck
Feature
| Casing Material | Die cast aluminium, epoxy powder coated |
| Colors | Yellow, other colors to special order |
| Handset Material | Cycoloy with stainless steel spiral cord |
| Keypad | No Keypad |
| Temperature |
Operating: -30°C to +65°C Storing: -40°C to +75°C |
| Weather Resistance | IP67 |
| Ringing Tone | Shrill warble tone 80 dBA @ 1 metre typical |
| Hook switch | Electronic / magnetic with no visible moving parts |
| M.T.B.F. | Calculated to have an M.T.B.F. in excess of 50,000 hours using |
| Weight | Up to 7 kg depending on option |
