Desk Type Hotline Emergency Phone For Guard Stations / Police Stations

Product Details

Place of Origin: Shenzhen, China

Brand Name: J&R

Certification: CE, FCC, RoHS, ISO9001

Model Number: JR204-CB

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Reconsideration

Packaging Details: pearl cotton, carton

Delivery Time: 2-5 working days

Payment Terms: L/C, T/T

Supply Ability: 3000 sets per month

Get Best Price
Product Details
High Light:

inmate phone

,

jail telephone

Material:
Cold Rolled Steel
Warranty:
2 Years
Weather Protection:
IP55-IP65
Handset:
ABS Material With Armored Cord
G.W:
3 KG
Mounting:
On Wall/desk Type
Auto-dial:
Yes
Communication Type:
Full Duplex
Material:
Cold Rolled Steel
Warranty:
2 Years
Weather Protection:
IP55-IP65
Handset:
ABS Material With Armored Cord
G.W:
3 KG
Mounting:
On Wall/desk Type
Auto-dial:
Yes
Communication Type:
Full Duplex
Product Description

Rugged Hotline Telephone for Guard Stations, Desk type Auto Dial Emergency Telephone



This Vandal Resistant Telephone with Voice Control Button is housed in robust steel box and manufactured to a high standard, it is offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times, resulting in a highly reliable product with a long MTBF.





APPLICATIONS

Ideal for Railway applications, Marine applications, Tunnels. Underground Mining, Firefighter, Industrial, Prisons, Jail, Parking lots, Hospitals, Guard Stations, Police stations, Bank halls, ATM machines, Stadiums, inside and outside building etc.





MAIN FEATURES

- Standard Analogue phone, or SIP phone

- Robust housing, constructed of stainless steel

- Weather proof protection IP65

- Vandal resistant armored cord handset



- Hot Line Auto-Dial Phones

- Phone lone powered (Analog)

- External Power supply or PoE (SIP phone)

- RJ45 port for SIP phone



- Inductive coupler fitted as standard for hard of hearing

- CE, FCC, RoHS, ISO9001 compliant





TECHNICAL PARAMETERS

Analogue Version
Power Supply From the analogue telephone network
Supply Voltage 24 VDC to 65 VDC
Supply Current 20 mA DC to 100 mA DC
Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.



SIP Version
Power Supply  PoE or 12V DC
Power Consumption  -Idle: 1.5W
 -Active: 1.8W
SIP Protocol  SIP 2.0 (RFC3261)
Support Codec  G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type  Full duplex
Ringer volume  - 90~95dB(A) at a distance of 1 m
 - 110dB(A) at a distance of 1 m (for external horn speaker)





PACKAGE

Unit size: 250 *160 *123 (mm)

Carton size: 340 *235 *165 (mm)

Packaging materials: pearl cotton, carton

Net weight: 3.5 KG

Gross weight: 4 KG
