Desk Type Hotline Emergency Phone For Guard Stations / Police Stations

Desk Type Hotline Emergency Phone For Guard Stations / Police Stations

Brand Name:	J&R
Model Number:	JR204-CB
MOQ:	1 set
Price:	Reconsideration
Payment Terms:	L/C, T/T
Supply Ability:	3000 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

CE, FCC, RoHS, ISO9001

Material:

Cold Rolled Steel

Warranty:

2 Years

Weather Protection:

IP55-IP65

Handset:

ABS Material With Armored Cord

G.W:

3 KG

Mounting:

On Wall/desk Type

Auto-dial:

Yes

Communication Type:

Full Duplex

Packaging Details:

pearl cotton, carton

Supply Ability:

3000 sets per month

Highlight:

inmate phone

jail telephone

Product Description

Rugged Hotline Telephone for Guard Stations, Desk type Auto Dial Emergency Telephone

This Vandal Resistant Telephone with Voice Control Button is housed in robust steel box and manufactured to a high standard, it is offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times, resulting in a highly reliable product with a long MTBF.

APPLICATIONS

Ideal for Railway applications, Marine applications, Tunnels. Underground Mining, Firefighter, Industrial, Prisons, Jail, Parking lots, Hospitals, Guard Stations, Police stations, Bank halls, ATM machines, Stadiums, inside and outside building etc.

MAIN FEATURES

- Standard Analogue phone, or SIP phone

- Robust housing, constructed of stainless steel

- Weather proof protection IP65

- Vandal resistant armored cord handset

- Hot Line Auto-Dial Phones

- Phone lone powered (Analog)

- External Power supply or PoE (SIP phone)

- RJ45 port for SIP phone

- Inductive coupler fitted as standard for hard of hearing

- CE, FCC, RoHS, ISO9001 compliant

TECHNICAL PARAMETERS

Analogue Version
Power Supply	From the analogue telephone network
Supply Voltage	24 VDC to 65 VDC
Supply Current	20 mA DC to 100 mA DC
Ringer Volume	- 80dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method	DTMF mode in accordance with ITU-T recommendation Q.23.

SIP Version
Power Supply	PoE or 12V DC
Power Consumption	-Idle: 1.5W -Active: 1.8W
SIP Protocol	SIP 2.0 (RFC3261)
Support Codec	G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type	Full duplex
Ringer volume	- 90~95dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker)

PACKAGE

Unit size: 250 *160 *123 (mm)

Carton size: 340 *235 *165 (mm)

Packaging materials: pearl cotton, carton

Net weight: 3.5 KG

Gross weight: 4 KG
