Anti Vandal SOS Industrial VoIP Phone Waterproof With Rugged Aluminum Enclosure

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, IP67, ISO9001:2015
Model Number: JR103-FK
Minimum Order Quantity: 1 set
Price: Reconsideration
Packaging Details: pearl cotton, carton
Delivery Time: 3-7 working days
Payment Terms: L/C, T/T
Supply Ability: 3000 sets per month
Detail Information
Material: Aluminum Alloy Color: Blue, Yellow, Orange (or Optional)
Power Supply: PoE Warranty: 2 Years
Weather Resistant: IP67 Size: 246 *339 *109 (mm)
Net Weight: 6 KG Installation: Wall/ Pillar Mounting
Anti-vandal: Yes Corrosion Resistant: Yes
High Light:

rugged voip phone

,

voice over ip phone

,

Anti Vandal Industrial VoIP Phone


Product Description

Anti-vandal Waterproof SOS VoIP Phone for Tunnel, Weatherproof Marine Telephone





 Applications
This weatherproof telephone is very popular for Tunnels, Mining, Marine, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants and relatedheavy duty industrial application, etc.




Main Features:
- Standard SIP/ VoIP phone
- Aluminum alloy die-casting body
- Vandal resistant handset and armored cord
- Weather proof protection to IP67



Full keypad with memory, 0-9 buttons can be programmed as speed dial button.
   “LR button for last number redial
   “R for flash recall
   “M for muting

Wall/ Pillar mounting, simple installation



- Inductive coupler fitted as standard for hard of hearing
- External power supply or PoE (SIP-VoIP)
- RJ45 port for SIP phone

- CE, FCC, ISO9001, RoHS compliant




SIP-VoIP Technical Parameters

SIP Version
Power Supply  PoE or 12V DC
Power Consumption  -Idle:1.5W
 -Active:1.8W
SIP Protocol  SIP 2.0 (RFC3261)
Support Codec  G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type  Full duplex
Ringer volume  - 90~95dB(A) at a distance of 1 m
 - 110dB(A) at a distance of 1 m (for external horn speaker)
Ambient conditions
Protection type  IP 66 as per EN60529
Operating temperature  -40°C to +70°C
Storage temperature  -45°C to +85°C



 Anti Vandal SOS Industrial VoIP Phone Waterproof With Rugged Aluminum Enclosure 0

Package

Unit Size:    339*246*109 mm (H *W * D)
Carton Dimension:   200 * 300 *440 mm (H * W * D)
Packaging materials:   pearl cotton, carton
Net Weight:    5 KG
Gross weight:    6 KG



Anti Vandal SOS Industrial VoIP Phone Waterproof With Rugged Aluminum Enclosure 1
