IP65 Stainless Steel Inmate Telephone For Jail And Drunk Tanks - JR201-FK

Name: IP65 Stainless Steel Inmate Telephone For Jail And Drunk Tanks - JR201-FK
Brand: J&R Technology Limited
SKU: JR201-FK
Price: 601.00 USD
Availability: InStock

Brand Name:	J&R
Model Number:	JR201-FK
MOQ:	1 set
Price:	Reconsideration
Payment Terms:	L/C, T/T, D/A, D/P
Supply Ability:	3000 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

CE, FCC, RoHS, ISO9001

Material:

Cold Rolled Steel

Warranty:

2 Years

Weather Protection:

IP55-IP65

Handset:

ABS Material

Keypad:

12-key Metal Keypad

Gross Weight:

3 KG

Color:

Grey Or Customized Color

Version:

Analog, SIP, GSM/3G

Packaging Details:

pearl cotton, carton

Supply Ability:

3000 sets per month

Highlight:

ABS material Vandal Resistant Inmate Telephone

Stainless Steel Inmate Telephone

Vandal Resistant Telephone For Jail

Product Description

Vandal Resistant Telephone with Rugged Handset and Metal Keypad

Encased in a sturdy cold rolled steel case and manufactured to a high standard, this vandal resistant phone with armored cords offers increased vandal resistance and ensures that the primary function of communication is always maintained.

APPLICATIONS

Ideal for rail applications, marine applications, and tunnels. Underground mining, firefighters, industry, prisons, jails, car parks, hospitals, guard stations, police stations, bank halls, ATM machines, sports venues, inside and outside buildings, etc.

MAIN FEATURES

- Standard Analogue phone

- Robust housing, constructed of cold rolled steel

- Weather proof protection up to IP55-IP65

- Vandal resistant handset

- Full metal keypad

- Non-volatile memory

- Can be programmed remotely by tone phone or locally via keypad

- Telephone line powered (Analog version )

- Available for SIP/VOIP version

- External Power supply or PoE powered (SIP version)

- RJ45 port for SIP phone

- On wall mounting, simple installation

- Inductive coupler fitted as standard for hard of hearing

- CE, FCC, RoHS, ISO9001 compliant

TECHNICAL PARAMETERS

Ambient conditions
Protection type	IP 66 as per EN60529
Operating temperature	-40°C to +70°C
Storage temperature	-45°C to +85°C

Analogue Version
Power Supply	From the analogue telephone network
Supply Voltage	24 VDC to 65 VDC
Supply Current	20 mA DC to 100 mA DC
Ringer Volume	- 80dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method	DTMF mode in accordance with ITU-T recommendation Q.23.

SIP Version
Power Supply	PoE or 12V DC
Power Consumption	-Idle: 1.5W -Active: 1.8W
SIP Protocol	SIP 2.0 (RFC3261)
Support Codec	G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type	Full duplex
Ringer volume	- 90~95dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker)

PACKAGE

unit size: 240 *100 *117 (mm)

Carton size: 340 *235 *165 (mm)

Packaging materials: pearl cotton, carton

Net weight: 2 KG

Gross weight: 3 KG
