Anti Vandal Industrial Weatherproof Telephone Wall Pillar Mining Marine SIP VoIP

Anti Vandal Industrial Weatherproof Telephone Wall Pillar Mining Marine SIP VoIP

Brand Name:	J&R
Model Number:	JR102-SC
MOQ:	1 set
Price:	Reconsideration
Payment Terms:	L/C, T/T
Supply Ability:	3000 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

CE, FCC, RoHS, IP67, ISO9001:2015

Material:

Aluminum Alloy

Weather Resistant:

IP67

Power Supply:

PoE, Or External Power Supply

Size:

246 *339 *126 (mm)

Color:

Yellow, Blue, Orange (or Optional)

Installation:

Wall/ Pillar Mounting

Net Weight:

12 KG (with Lamp&horn)

Anti-vandal:

Yes

Warranty:

2 Years

Packaging Details:

pearl cotton, carton

Supply Ability:

3000 sets per month

Highlight:

Anti Vandal Industrial Weatherproof Telephone

Wall Pillar Industrial Weatherproof Telephone

Mining Marine Waterproof Emergency Phone

Product Description

Waterproof intercom SIP/VoIP telephone Mining / Marine Emergency Phone

This VoIP Hazardous Area Telephones offers a rugged aluminum enclosure with pivoted door and a weatherproof rating of IP67. It's a Safe, reliable. Voice over Internet Protocol (VoIP) phone requires a simple network connection and are compatible with most SIP-based IP-PBX servers to integrate into your existing network infrastructure.

For connection to a VoIP enable network, J&R'S VoIP-SIP telephones offer direct connection to LAN or WAN via RJ45 connector, including Power-Over-Ethernet (PoE) as standard. J&R'S VoIP-SIP phones offer a wealth of additional features, and can be configured by web browser.

Main Features:

- Standard SIP/VoIP phone
- Aluminum alloy die-casting body
- Weather proof protection to IP67
- Vandal resistant metal button for Emergency
- Hands free operation
- Wall/ Pillar mounting, simple installation
- The phone will ringing loudly and lamp will flashing when there is a incoming call.
- With auto-answer feature after 5 ringing, Auto- release the line when the other side cut off the line.
- External power supply or PoE (SIP-VoIP)
- RJ45 port for SIP phone
- Inductive coupler fitted as standard for hard of hearing
- CE, FCC, ISO9001, RoHS compliant

Technical Parameters

SIP Version
Power Supply	PoE or 12V DC
Power Consumption	-Idle: 1.5W -Active: 1.8W
SIP Protocol	SIP 2.0 (RFC3261)
Support Codec	G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type	Full duplex
Ringer volume	- 90~95dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker)

Ambient conditions
Protection type	IP 67 as per EN60529
Operating temperature	-40°C to +70°C
Storage temperature	-45°C to +85°C
Weight	Up to 6 KG depending on option

Anti Vandal Industrial Weatherproof Telephone Wall Pillar Mining Marine SIP VoIP 0

Anti Vandal Industrial Weatherproof Telephone Wall Pillar Mining Marine SIP VoIP 1

Applications

This weatherproof industrial telephone is very popular for Tunnels, Mining, Marine, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants and relatedheavy duty industrial application, etc.

Anti Vandal Industrial Weatherproof Telephone Wall Pillar Mining Marine SIP VoIP 2
