SIP 2.0 Weatherproof Hotline Telephone Anti Vandal IP67 Wall Pillar

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR103-CB-SIP
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Unit size: 339*246*126 (mm) Carton size: 200*300*440 (mm ) Packaging materials: Pearl cotton, Carton Net weight: 6.2KG Gross weight: 7KG
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T
Supply Ability: 3000 sets per month
Detail Information
Material: Die-casting Aluminum Alloy Function: SOS
Main Chip: Audiocodec Package: Pearl Cotton, Carton
Modle: Analog/ SIP/ GSM/ 3G Mounting: Wall /Pillar Mounted
Ingress Protection Rating: IP66-IP67 Door Cover: Yes
Handset: Yes Temperature: -30°C To +65°C
OEM: Yes Warranty: 2 Years
Feature1: Hotline Feature2: Anti Vandal
Net Weight: 5kg Gross Weight: 7kg
High Light:

SIP 2.0 Weatherproof Hotline Telephone

,

Anti Vandal Weatherproof Hotline Telephone

,

Wall Pillar Waterproof Emergency Phone


Product Description



Hotline Telephone IP67 Water Resistant Industrial Telephone



JR103-CB-SIP is an automatic dialing phone. The user only needs to pick up the handset, and the phone will automatically connect to the relevant department, which is convenient for the user to seek emergency help or consultation. In addition, relevant departments can control and manage the SIP emergency phone to ensure low-cost and high-efficiency operation of the phone. In addition, the JR weather-resistant hotline phone is equipped with stainless steel security screws to protect the phone from theft and vandalism.



SIP 2.0 Weatherproof Hotline Telephone Anti Vandal IP67 Wall Pillar 0





Hotline Telephone IP67 Water Resistant Industrial Telephone

SIP Version



Power Suppl

PoE or 12V D

Power Consumptio -Idle:1.5W / -Active:1.8W
SIP Protocol SIP 2.0 (RFC3261)
Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type Picking machine automatic dialing
Handset Cycoloy with stainless steel spiral cord
Hook switch Electronic / magnetic with no visible moving parts
Ringer volume - 90~95dB(A) at a distance of 1 m / - 110dB(A) at a distance of 1 m (for external horn speaker)
Temperature Operating: -25°C to +70°C
Storing: -25°C to +80°C
Weather Resistance IP67
Weight Up to 6 KG depending on option



  • ★ Casing Material : Die cast aluminium, epoxy powder coated.
    ★ Colors : Yellow, other colors to special order
    ★ CB version: Programmable for auto-dial
    ★ Handset Material : Cycoloy with stainless steel spiral cord
    ★ Weather Resistance : IP67
    ★ M.T.B.F. : Calculated to have an M.T.B.F. in excess of 50,000 hours using



Hotline Telephone IP67 Water Resistant Industrial Telephone

As a weatherproof telephone, it is fully contained within a corrosion resistant cast aluminium weatherproof case with a door providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF. Ideal for Metro, Railway, Highway side, Marine, Mining, Tunnels, Steel Plant, Chemical plant, Power plant and related industrial application, etc.



-JR103-CB_07
