Anti Vandal Hotline Industrial Telephone IP67 SIP GSM Pillar Mounted

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR101-CB-SIP
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Unit size: 339*246*126 (mm) Carton size: 200*300*440 (mm ) Packaging materials: Pearl cotton, Carton Net weight: 6.2KG Gross weight: 7KG
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T
Supply Ability: 3000 sets per month
Detail Information
Product Name: Highway Emergency Call Box Industrial Waterproof Telephone For Roadside Material: Die-casting Aluminum Alloy
Function: SOS Main Chip: Audiocodec
Package: Pearl Cotton, Carton Modle: Analog/ SIP/ GSM/ 3G
Mounting: Wall /Pillar Mounted Ingress Protection Rating: IP66-IP67
Full Keypad: Yes Door Cover: Yes
Handset: Yes Temperature: -30°C To +65°C
OEM: Yes Warranty: 2 Years
Feature1: Hotline Feature2: Anti Vandal
Net Weight: 6kg Gross Weight: 7kg
High Light:

Anti Vandal Hotline Industrial Telephone


Pillar Mounted Hotline Industrial Telephone


SIP GSM Weatherproof Hotline Telephone

Product Description


IP67 Waterproof hotline Telephone


JR101-CB-SIP is an automatic dialing phone. The user only needs to pick up the handset, and the phone will automatically connect to the relevant department, which is convenient for the user to seek emergency help or consultation. In addition, relevant departments can control and manage the SIP emergency phone to ensure low-cost and high-efficiency operation of the phone. In addition, the JR weather-resistant hotline phone is equipped with stainless steel security screws to protect the phone from theft and vandalism.


SIP Version


Power Suppl

PoE or 12V D

Power Consumptio -Idle:1.5W / -Active:1.8W
SIP Protocol SIP 2.0 (RFC3261)
Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type Picking machine automatic dialing
Handset Cycoloy with stainless steel spiral cord
Hook switch Electronic / magnetic with no visible moving parts
Ringer volume - 90~95dB(A) at a distance of 1 m / - 110dB(A) at a distance of 1 m (for external horn speaker)
Temperature Operating: -25°C to +70°C
Storing: -25°C to +80°C
Weather Resistance IP67
Weight Up to 6 KG depending on option





IP67 Waterproof hotline Telephone


  • ★ Casing Material : Die cast aluminium, epoxy powder coated.
    ★ Colors : Yellow, other colors to special order
    ★ CB version: Programmable for auto-dial
    ★ Handset Material : Cycoloy with stainless steel spiral cord
    ★ Weather Resistance : IP67
    ★ M.T.B.F. : Calculated to have an M.T.B.F. in excess of 50,000 hours using


Hotline Telephone



IP67 Waterproof hotline Telephone

As a weatherproof telephone, it is fully contained within a corrosion resistant cast aluminium weatherproof case with a door providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF. Ideal for Metro, Railway, Highway side, Marine, Mining, Tunnels, Steel Plant, Chemical plant, Power plant and related industrial application, etc.
