JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR202-CB
Minimum Order Quantity: 1 piece
Price: negotiable
Packaging Details: pearl cotton, carton
Delivery Time: 3-5 working days after payment
Payment Terms: L/C, T/T,paypal, Western Union
Supply Ability: 3000 sets per month
Detail Information
Material: Cold Rolled Steel Or Stainless Steel Warranty: 2 Years
Weather Protection: IP55-IP65 Handset: ABS Material With Armored Cord
Size: 247 *130 *132 (mm) Weight: 3.5 KG
Version: Analogue/SIP/GSM Powered: Telephone Line Powered Or DC12V
Product Name: Full Keypad Public Emergency Vandal Resistant Prison Telephone For Bank
High Light:

GSM Vandal Resistant Hotline Telephone

,

DC12V Vandal Resistant Hotline Telephone

,

spiral cord Rugged Dial Phones


Product Description

Product Description

JR202-CB Vandal Resistant Hotline Telephone, Rugged Auto-dial Phones for Parking-lots


Vandal resistant handset with Holder to fixed better.

Standard hook switch is Magnetic Hook,available for mechanical hook.





JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 0









Casing Material Cold rolled steel body
Colors RED, YELLOW, GREY
Handset Material ABS material handset with stainless steel spiral cord
Keypad No Keypad
Temperature

Operating: -30°C to +65°C

Storing: -40°C to +75°C

Weather Resistance

IP55-IP65

Ringing Tone Shrill warble tone 80 dBA at 1 metre typical
Hook Switch Electronic / magnetic with no visible moving parts
M.T.B.F. Calculated to have an M.T.B.F. in excess of 50,000 hours using
Weight Up to 4 kg depending on option









Technical Specification

Vandal Resistant Hotline Telephone, Rugged Auto-dial Phones for Parking-lots


JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 1

JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 2

    Analogue Version
    Power Supply From the analogue telephone network
    Supply Voltage 24 VDC to 65 VDC
    Supply Current 20 mA DC to 100 mA DC
    Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
    Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.



    SIP Version
    Power Supply PoE or 12V DC
    Power Consumption -Idle:1.5W
-Active:1.8W
    SIP Protocol SIP 2.0 (RFC3261)
    Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
    Communication Type Full duplex
    Ringer Volume - 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)



    Ambient conditions
    Protection Type IP 66 as per EN60529
    Operating Temperature -25°C to +70°C
    Storage Temperature -25°C to +85°C









Features

Vandal Resistant Hotline Telephone, Rugged Auto-dial Phones for Parking-lots


JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 3



   ◐ Robust housing, constructed of stainless steel



   ◐ Vandal resistant armored cord handset



   ◐ Inductive coupler fitted as standard for hard of hearing



   ◐ Impact, shock, fall and vibration proof,able to perform in difficult environments



   ◐ On wall mounting, simple installation









Packing & Delivery

J&R Heavy Duty, Vandal Resistant Metal Telephones for Hospital, Jail, Airport, ATM


JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 4

Unit Size 240 *100 *117(mm)
Carton Size 340 *235 *165 (mm)
Packaging Materials Pearl cotton, carton
Net Weight 3.5 KG
Gross Weight 4 KG



JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 5



Port Shenzhen, Guangdong

Lead Time

(If you finish the payment today, your order will ship out within the delivery date.)

Quantity(Sets) 1 2-500 >500
Est. Time(Days) 2 25 To be negotiated









Our Services

J&R Heavy Duty, Vandal Resistant Metal Telephones for Hospital, Jail, Airport, ATM


JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 6



    ◑ ODM & OEM products or solutions



    ◑ Sample order is greatly welcomed



    ◑ We will reply your inquiry within 12 hours



    ◑ Update the productive process and show the packing details



    ◑ After delivered the goods, we will track the products for you once every two days, until you get the products.



    ◑ When you got the products, if there is any further questions, welcome to contact us and we will solve the problems for you in time.









Our Company

J&R Heavy Duty, Vandal Resistant Metal Telephones for Hospital, Jail, Airport, ATM


J&R is China based design and manufacturer of rugged communications equipment. Our telephones and systems work, and last, in environments where regular products wouldn’t.

(All Of Our Phone Model Avaliable For Analogue Version,IP/SIP Versio,GSM/3G/4G Version)
After well study your information,we sincerely hope to enter into partnership with your esteemed compnay.and we hope to serve you and cooperate with you for all of our product range in your market.
We could offer you all of our product range with ODM&OEM solution to meet your demands and requirement well.



JR202-CB DC12V GSM Vandal Resistant Hotline Telephone Spiral Cord 7





FAQ

J&R Heavy Duty, Vandal Resistant Metal Telephones for Hospital, Jail, Airport, ATM


  Q: Do you have any MOQ limit?
  A: Low MOQ, 1pc is available


  Q: Can I have a sample order ?
  A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.


  Q: What do IP Ratings mean?
  A: IP Ratings apply to enclosures such as our telephone cabinets. They indicate how the enclosure protects against water and dust ingress, the higher the better.


  Q: How to proceed an order ?
  A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.


  Q: How can I pay you?
  A: Many convenient methods for choose: Paypal, T/T, L/C.


  Q: What about the lead time?
  A: Normally within 2-5 working days. We have materials in stock for most of hot selling products.And mass production time needs 2-4 weeks for order quantity more than 100 units.


  Q: Do you offer guarantee for the products?
  A: Yes, we offer 2 years warranty to our products against delivery.


  Q: What's the quality standard of your products?
  A: CE, FCC, RoHS, ISO9001:2015 certification approved. All materials are in high grade and new. With the strict quality, every phone be thoroughly tested before leaving the factory.


  Q: Is it OK to print my logo on the products?
  A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.


  Q: Can you produce a product in a color of my choosing?
  A: Yes, we can manufacture products in different colors, however there may be minimum quantities or surcharges applicable.


  Q: Do you provide an installation service?
  A: No, we do not install products, but they are very straightforward to install, please kindly contact us if unsure.



  Q: How about the shipping?
  A: 1.Send by DHL / TNT / UPS / FEDEX / EMS,3-5days
       2.Send by Air: Arrive at destination Airport fast then pick it up by yourself
       3.Ship by Sea: Low shipping cost and slow delivery (15 - 30 days)



  Q: How to deal with the faulty?
  A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
