Home ProductsExplosion Proof Telephone

Wall Pillar Mounting IP67 IP Explosion Proof Telephone

China J&R Technology Limited certification
China J&R Technology Limited certification
I'm Online Chat Now

Wall Pillar Mounting IP67 IP Explosion Proof Telephone

Wall Pillar Mounting IP67 IP Explosion Proof Telephone
Wall Pillar Mounting IP67 IP Explosion Proof Telephone
video play

Large Image :  Wall Pillar Mounting IP67 IP Explosion Proof Telephone

Product Details:
Place of Origin: Shenzhen,Guangdong,China
Brand Name: J&R
Certification: CE, FCC, RoHS, ATEX
Model Number: JREX101
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: US $455 ~ US $550 (negotiable)
Packaging Details: J&R standard packing ,pearl cotton, carton
Delivery Time: 3-7 working days after payment
Payment Terms: L/C, T/T, Western Union,Paypal
Supply Ability: 10000 pcs per month
Detailed Product Description
Color: Orange,Yellow,Red Or Customized Version: Analog, SIP,IP,VoIP
Installation: Wall Mounting Or Pillar Mounting Warranty: 2 Years
Net Weight: 7 KG Gross Weight: 8 KG
Ingress Protection: IP67 Applications: Mine,Oil Rigs,Tunnel,Petrol Station,metro Etc
High Light:

Pillar Mounting Explosion Proof Telephone

,

IP67 IP Explosion Proof Telephone

,

85dbA Explosion Proof Ip Phone



Product Description

JREX101-HB IP Sound and Light Explosion-proof Telephone




This IP Sound and Light Explosion-proof Telephone is designed for voice communication in the hostile environment where reliability, efficiency and safety are of prime importance.
The telephone can handle the large temperature differences found outdoors, high humidity, exposure to sea water and dust, corrosive atmosphere, explosive gases & particles, as well as mechanical wear and tear, making it perfect for use as an emergency telephone.







Casing Material

Die cast aluminium, epoxy powder coated

Handset Material

Cycoloy with stainless steel spiral cord

Protection Type

IP66-IP67
Hookswitch Electronic / magnetic with no visible moving parts

Explosion Protection

II 2G Ex e ib [ib] mb IIC T4 Gb
II 2D Ex ib [ib] tb IIIC T135 °Db
-40 °C ≤ Ta ≤ +60 °C/+40°C
Zone 1, 2, 22

Ringing Tone

Built-in External Ringer that provides penetrating calling signal

(85 dbA at 1meter)

M.T.B.F. excess of 50,000 hours using
Weight Up to 8 kg depending on option
Keypad

Weather resistant full Keypad,

No.of keys(TOTAL15KEYS):0-9,*,#,Redial,Mute,Last Number Redial





Wall Pillar Mounting IP67 IP Explosion Proof Telephone 0











Technical Specification

IP Sound and Light Explosion-proof Telephone




Wall Pillar Mounting IP67 IP Explosion Proof Telephone 1



  Analogue Version
  Power Supply From the analogue telephone network
  Supply Voltage 24 VDC to 65 VDC
  Supply Current 20 mA DC to 100 mA DC
  Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance
of 1 m (for external horn speaker)
  Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.



  SIP Version
  Power Supply PoE or 12V DC
  Power Consumption -Idle:1.5W
-Active:1.8W
  SIP Protocol SIP 2.0 (RFC3261)
  Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
  Communication Type Full duplex
  Ringer volume - 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)



  Ambient conditions
  Protection type IP 66 as per EN60529
  Operating temperature -25°C to +70°C
  Storage temperature

-25°C to +85°C













Features

IP Sound and Light Explosion-proof Telephone




Wall Pillar Mounting IP67 IP Explosion Proof Telephone 2



 ★ Zone classification: Zone 1& Zone 2

 ★ Corrosion resistant aluminum alloy die casting housing

 ★ Certificated for use in Hazardous areas of Gas Group IIB/IIA

 ★ Fully configurable through any internet browser or the on-board display

 ★ Available in four colors, with NPT conduit entries and Type 3 / IP67 environmental ratings









Applications

IP Sound and Light Explosion-proof Telephone


Wall Pillar Mounting IP67 IP Explosion Proof Telephone 3













Packing & Delivery

IP Sound and Light Explosion-proof Telephone




Wall Pillar Mounting IP67 IP Explosion Proof Telephone 4



Unit size 204*334*126 (mm)
Carton size 340 *240 *160 (mm)
Packaging materials pearl cotton, carton
Net weight 7 KG
Gross weight

8 KG





Wall Pillar Mounting IP67 IP Explosion Proof Telephone 5



Port Shenzhen, Guangdong, China

Lead Time

(If you finish the payment today, your order will ship out within the delivery date.)

Quantity(Sets) 1-10 11-50 51-200 >200
Est.Time(Days) 2 10 20 To be negotiated













Care and Maintenance

IP Sound and Light Explosion-proof Telephone


Wall Pillar Mounting IP67 IP Explosion Proof Telephone 6



  The telephone is maintenance-free. Still, if the operating area is highly contaminated by dust, fat, oil etc., the device should be cleaned from time to time. Use a moist cloth to dust off the receiver and the device.



 ◉ Warning! Never use sharp objects for cleaning. Do not use other polishing or abrasive substances. Movable parts of the housing may NOT (!) be covered by lubricants like oil, grease etc.!









Our Company

IP Sound and Light Explosion-proof Telephone


J&R is China based design and manufacturer of rugged communications equipment.

Our telephones and systems work, and last, in environments where regular products wouldn’t.

(All Of Our Phone Model Avaliable For Analogue Version,IP/SIP Version,GSM/3G/4G Version)
After well study your information,we sincerely hope to enter into partnership with your esteemed company

and we hope to serve you and cooperate with you for all of our product range in your market.
We could offer you all of our product range with ODM&OEM solution to meet your demands and requirement well.



Wall Pillar Mounting IP67 IP Explosion Proof Telephone 7









Our Customers

IP Sound and Light Explosion-proof Telephone


 Wall Pillar Mounting IP67 IP Explosion Proof Telephone 8
