Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation

Good quality Industrial VoIP Phone for sales
Good quality Industrial VoIP Phone for sales
I'm Online Chat Now

Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation

China Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier
Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation supplier

Large Image :  Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation

Product Details:

Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR104-2B

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece
Price: US$119-US$369
Packaging Details: J&R standard packing ,pearl cotton, carton
Delivery Time: 3-7 working days after payment
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 10000pcs per month
Contact Now
Detailed Product Description
Color: Yellow Or Customized Material: Die-casting Aluminum Alloy
Version: Analogue, SIP, GSM, 3G Installation: Wall Mounting
Warranty: 2 Years Weight: 5 KG
Size: 204 *334 *74(mm) Keypad: No Keypad
Power Input: 12-24V DC Weather Resistance: IP66



Product Description

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


This heavy duty hotline telephone is fully contained within a corrosion resistant cast aluminium weatherproof case, which providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.







 Casing Material
Die cast aluminium body, cold rolled steel paceplate epoxy powder coated
 Colors
yellow, other colors to special order
 Handset Material
No handset
 Keypad
No Keypad
 Temperature
Operating: -30°C to +65°C
Storing: -40°C to +75°C
 Weather Resistance
IP66-IP67
 Ringing Tone
Shrill warble tone 90 dBA @ 1 metre typical
 Hook switch
No hook switch
 Push button
Vandal resistant stainless steel button
 M.T.B.F.
Calculated to have an M.T.B.F. in excess of 50,000 hours using
 Weight
Up to 6 kg depending on option
 Power Input
12-24V DC





Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation





Technical Specification

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation

 Analogue Version
 Power Supply From the analogue telephone network
 Supply Voltage 24 VDC to 65 VDC
 Supply Current 20 mA DC to 100 mA DC
 Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
 Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.



 SIP Version
 Power Supply PoE or 12V DC
 Power Consumption -Idle:1.5W
-Active:1.8W
 SIP Protocol SIP 2.0 (RFC3261)
 Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
 Communication Type Full duplex
 Ringer Volume - 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)



 Ambient conditions
 Protection Type IP 66 as per EN60529
 Operating Temperature -30°C to +65°C
 Storage Temperature -40°C to +75°C











Features

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation



    ◈ Hands free operation

    ◈ Wall / Pillar mounting, simple installation

    ◈ The phone will ringing loudly when there is a incoming call

    ◈ Single or Dual button auto dial options with remote programming

    ◈ With auto-answer feature after 5 ringing, Auto-release the line when the other side cut off the line







Packing & Delivery

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation



Unit Size 204 *334 *74(mm)
Carton Size 200 *300 *440 (mm)
Packaging Materials Pearl cotton, carton
Net Weight 4 KG
Gross Weight 5 KG



Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation



Port Shenzhen, Guangdong

Lead Time

(If you finish the payment today, your order will ship out within the delivery date.)

Quantity(Sets) 1 2-500 >500
Est. Time(Days) 2 25 To be negotiated











Our Services

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation



     ◊ ODM & OEM products or solutions



     ◊ Sample order is greatly welcomed



     ◊ We will reply your inquiry within 12 hours



     ◊ Update the productive process and show the packing details



     ◊ After delivered the goods, we will track the products for you once every two days, until you get the products



     ◊ When you got the products, if there is any further questions, welcome to contact us and we will solve the problems for you in time







Our Company

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


J&R is one of the most professional manufacturers of emergency telephones, industrial telephones, Explosion-proof Telephones, and public telephones in Asia. The successful cooperation with thousands of customers all over the world and the supports to hundreds of projects have made us a reliable and popular supplier of industrial phones and phone accessories.

Our main products include weatherproof phones, Explosion proof telephone, prison phones, emergency phones, elevator phones , acoustic phone booths and telephone kits as well.

Two Button Industrial Weatherproof Telephone Wall Mounting Simple Installation





FAQ

Simple Installation Industrial Telephone with Two Button for Mine, Underground, Roadside


Q: Do you have any MOQ limit?

A: Low MOQ, 1pc is available



Q: Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q: What do IP Ratings mean?
A: IP Ratings apply to enclosures such as our telephone cabinets. They indicate how the enclosure protects against water and dust ingress, the higher the better.

Q: How to proceed an order ?

A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.



Q: When can I receive your quotation?

A: Within 12 hours


Q: How can I pay you?
A: Many convenient methods for choose: Paypal, T/T, L/C.


Q: What about the lead time?
A: Normally within 2-5 working days. We have materials in stock for most of hot selling products.And mass production time needs 2-4 weeks for order quantity more than 100 units.



Q: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products against delivery.

Q: What's the quality standard of your products?

A: CE, FCC, RoHS, ISO9001:2015 certification approved. All materials are in high grade and new. With the strict quality, every phone be thoroughly tested before leaving the factory.

Q: Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q: Do you provide an installation service?
A: No, we do not install products, but they are very straightforward to install, please kindly contact us if unsure.

Q: How about the shipping?
A: 1.Send by DHL / TNT / UPS / FEDEX / EMS,3-5days
2.Send by Air: Arrive at destination Airport fast then pick it up by yourself
3.Ship by Sea: Low shipping cost and slow delivery (15 - 30 days)


Q: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly,

during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair

them and resend them to you or we can discuss the solution including re-call according to real situation.
