| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | J&R |
| Certification: | CE, FCC, RoHS, IP67, ISO9001:2015 |
| Model Number: | JR101-FK |
| Minimum Order Quantity: | 1 Piece |
| Price: | US$229 - US$399 |
| Packaging Details: | J&R standard packing ,pearl cotton, carton |
| Delivery Time: | 3-7 working days after payment |
| Payment Terms: | L/C, T/T, Western Union，PayPal |
| Supply Ability: | 10000pcs per month |
| Color: | Yellow, Blue, Red Or Customization | Material: | Die-casting Aluminum Alloy |
|---|---|---|---|
| Version: | Analogue, SIP/VoIP, GSM/3G/4G | Installation: | Wall Mounting Or Pillar Mounting Or Column Mounting |
| Powered: | POE Or DC12V Powered Or Telephone Line Powered | Warranty: | 2years |
| Ringing Volume: | 75-90db | Protection Type: | IP65-IP67 |
| SIP Protocol: | SIP2.0 | Application: | Metro, Railway, Highway Side,Tunnel,Roadside Etc |
| High Light: | weatherproof telephone box,outdoor weatherproof telephones |
||
﹄Product Description﹃
JR101-FK SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone
| Casing Material | Die cast aluminium, epoxy powder coated |
| Colors | Yellow, other colors to special order |
| Handset Material | Cycoloy with stainless steel spiral cord |
| Keypad | Rubber Keypad |
| Temperature | Operating: -30°C to +65°C Storing: -40°C to +75°C |
| Weather Resistance | IP67 |
| Ringing Tone | Shrill warble tone 80 dB A at 1 metre typical |
| Hook switch | Electronic / magnetic with no visible moving parts |
| M.T.B.F. | Calculated to have an M.T.B.F. in excess of 50,000 hours using Relative humidity:Up to 95% (non-condensing) |
| Weight | Up to 6 kg depending on option |
| Analogue Version | |
| Power Supply | From the analogue telephone network |
| Supply Voltage | 24 VDC to 65 VDC |
| Supply Current | 20 mA DC to 100 mA DC |
| Ringer Volume | - 80dB(A) at a distance of 1 m |
| - 110dB(A) at a distance of 1 m (for external horn speaker) | |
| Dialing Method | DTMF mode in accordance with ITU-T recommendation Q.23. |
| SIP Version | |
| Power Supply | PoE or 12V DC |
| Power Consumption | -Idle:1.5W -Active:1.8W |
| SIP Protocol | SIP 2.0 (RFC3261) |
| Support Codec | G.711 A/U, G.722 8000/16000, G.723, G.729 |
| Communication Type | Full duplex |
| Ringer volume | - 90~95dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker) |
| 3G Version | |
| Power Supply | 12V DC |
| Power Consumption |
-Idle:0.3W -Active: 1.5W
|
| Communication Type | Full duplex |
| Ringer volume | 90~95dB(A) at a distance of 1 m |
| Program Method | Remote programming by SMS |
| Frequency | A version: - Dual-Band WCDMA/HSDPA 850/1900MHz - Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz E version: - Dual-Band UMTS/HSDPA 900/2100MHz - Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz J version: - Dual-Band UMTS/HSDPA 850(800)/2100MHz - Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz |
| Ambient conditions | |
| Protection type | IP 66 as per EN60529 |
| Operating temperature | -25°C to +70°C |
| Storage temperature | -25°C to +85°C |
﹄Technical Specification﹃
SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone with Full Keypad
﹄Features﹃
SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone with Full Keypad
∫ Standard Analogue phone,or SIP phone,or GSM/3G phone
∫ Vandal resistant handset and armored cord
∫ Weather proof protection to IP67
∫ Full keypad with memory, 0-9 buttons can be programmed as speed dial button.
∫ Wall mounting, simple installation
∫ Very easy for operation, maintenance and management
﹄Packing & Delivery﹃
SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone with Full Keypad
| Unit size | 204 *334 *126(mm) |
| Carton size | 200*300*440( mm ) |
| Packaging materials | pearl cotton, carton |
| Gross weight | 7 KG |
| Net weight | 6 KG |
| Port | Shenzhen | |||
|
Lead Time (If you finish the payment today, your order will ship out within the delivery date.) |
Quantity(Units) | 1 | 2-500 | >500 |
| Est. Time(days) | 1 | 20 | To be negotiated | |
﹄Our Services﹃
SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone with Full Keypad
1. ODM & OEM products or solutions
2. Sample order is greatly welcomed.
3. We will reply your inquiry within 12 hours
4. Update the productive process and show the packing details
5. After delivered the goods, we will track the products for you once every two days, until you get the products.
6.When you got the products, if there is any further questions, welcome to contact us and we will solve the problems for you in time.
﹄Our Company﹃
SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone with Full Keypad
﹄FAQ﹃
SIP/VoIP/Analog Moisture Resistant Marine Weatherproof Telephone with Full Keypad
Q: Do You Have Any MOQ Limit?
A: Low MOQ, 1pc Is Available
Q: Can I Have A Sample Order ?
A: Yes, We Welcome Sample Order To Test And Check Quality.Mixed Samples Are Acceptable.
Q: What About The Lead Time?
A: Normally Within 2-5 Working Days. We Have Materials In Stock For Most Of Hot Selling Products.And Mass Production Time Needs 2-4 Weeks For Order Quantity More Than 100 Units.
Q: What's the quality standard of your products?
A: CE, FCC, RoHS, ISO9001:2015 certification approved. All materials are in high grade and new. With the strict quality, every phone be thoroughly tested before leaving the factory.
Q: Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q: Can you produce a product in a color of my choosing?
A: Yes, we can manufacture products in different colors, however there may be minimum quantities or surcharges applicable.
Q: Do you provide an installation service?
A: No, we do not install products, but they are very straightforward to install, please kindly contact us if unsure.
Q: When can I receive your quotation?
A: Once learn your detail requirements.
Q: How can I pay you?
A: Many convenient methods for choose: Paypal, T/T, L/C.
Q: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products against delivery.
Q: How about the shipping?
A: 1.Send by DHL / TNT / UPS / FEDEX / EMS,3-5days
2.Send by Air: Arrive at destination Airport fast then pick it up by yourself
3.Ship by Sea: Low shipping cost and slow delivery (15 - 30 days)
Q: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
