IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR103-CB
Minimum Order Quantity: 1 Piece
Price: negotiable
Packaging Details: J&R standard packing ,pearl cotton, carton
Delivery Time: 3-7 working days after payment
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 10000pcs per month
Detail Information
Color: Yellow Or Customized Material: Die-casting Aluminum Alloy
Version: Analogue, SIP, GSM, 3G Installation: Wall Mounting
Warranty: 2 Years Weight: 5 KG
Size: 204 *334 *74(mm) Function: SOS
Power Input: 12-24V DC Weather Resistance: IP66-IP67
Packaging Materials: Pearl Cotton, Carton Door: Optional
Feature: Hotline Product Name: Outdoor Hotline Speed Dial Emergency Weatherproof Telephone For Tunnel
High Light:

weather resistant telephone

,

weatherproof telephone box


Product Description

Product Description

Hotline Speed Dial waterproof Emergency weather resistant phone


The industrial telephones are fully contained within a corrosion resistant cast aluminium weatherproof case with a door providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.
JR103-CB is designed for voice communication in the hostile envirronment where reliability, efficiency and safety are of prime importance.



Feature

Yellow color IP67 waterproof hotline PASTN tunnel telephone


Standard Analogue phone/ SIP phone
Vandal resistant handset and cord
Weather proof protection to IP66
Full keypad with memory, 0-9 buttons can be programmed as speed dial button
"LR" button for last number redial
"R" for flash recall
"M" for muting
Wall mounting, Easy for installation
Inductive coupler fitted as standard for hard of hearing, with LCD display
Phone line power supply or PoE (SIP-VoIP)
RJ45 port for SIP phone
CE, FCC, ROSH compliant





Specification

Yellow color IP67 waterproof hotline PASTN tunnel telephone



Yellow color IP67 waterproof hotline PASTN tunnel telephone

Analogue Version
Power Supply
From the analogue telephone network
Supply Voltage
24 VDC to 65 VDC
Supply Current
20 mA DC to 100 mA DC

Ringer Volume
- 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method
DTMF mode in accordance with ITU-T recommendation Q.23.
SIP Version
Power Supply
PoE or 12V DC
Power Consumption
-Idle:1.5W
-Active:1.8W
SIP Protocol
SIP 2.0 (RFC3261)
Support Codec
G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type
Full duplex

Ringer volume
- 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
3G Version
Power Supply
12V DC
Power Consumption
-Idle:0.3W
-Active: 1.5W
Communication Type
Full duplex
Ringer volume
90~95dB(A) at a distance of 1 m
Program Method
Remote programming by SMS




Frequency
A version:
- Dual-Band WCDMA/HSDPA 850/1900MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
E version:
- Dual-Band UMTS/HSDPA 900/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
J version:
- Dual-Band UMTS/HSDPA 850(800)/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
Ambient conditions
Protection type
IP 66 as per EN60529
Operating temperature
-25°C to +70°C
Storage temperature
-25°C to +85°C



IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 0IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 1



Application



Yellow color IP67 waterproof hotline PASTN tunnel telephone


The phone is suitable for use in harsh environment characterized by: indoor & outdoor, Presence of dust & water ingress.for Tunnels, Mining, Marine, Construction sites, Blast furnace areas, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants, oil&Gas station, and related heavy duty industrial rough environment conditions, etc.
IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 2

IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 3

IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 4

IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 5

IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 6IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 7IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 8IP67 Waterproof Hotline PASTN Tunnel Industrial Voip Phone 2 Years Warranty 9
