| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | J&R |
| Certification: | CE, FCC, RoHS, ISO9001 |
| Model Number: | JR103-CB |
| Minimum Order Quantity: | 1 Piece |
| Price: | negotiable |
| Packaging Details: | J&R standard packing ,pearl cotton, carton |
| Delivery Time: | 3-7 working days after payment |
| Payment Terms: | L/C, T/T, Western Union，PayPal |
| Supply Ability: | 10000pcs per month |
| Color: | Yellow Or Customized | Material: | Die-casting Aluminum Alloy |
|---|---|---|---|
| Version: | Analogue, SIP, GSM, 3G | Installation: | Wall Mounting |
| Warranty: | 2 Years | Weight: | 5 KG |
| Size: | 204 *334 *74(mm) | Function: | SOS |
| Power Input: | 12-24V DC | Weather Resistance: | IP66-IP67 |
| Packaging Materials: | Pearl Cotton, Carton | Door: | Optional |
| Feature: | Hotline | Product Name: | Outdoor Hotline Speed Dial Emergency Weatherproof Telephone For Tunnel |
| High Light: | weatherproof telephone box,outdoor weatherproof telephones |
||
Outdoor Hotline Speed Dial Emergency Weatherproof Telephone for Tunnel
The industrial telephones are fully contained within a corrosion resistant cast aluminium weatherproof case with a door providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.
JR103-CB is designed for voice communication in the hostile envirronment where reliability, efficiency and safety are of prime importance.
Outdoor Hotline Speed Dial Emergency Weatherproof Telephone for Tunnel
Standard Analogue phone/ SIP phone
Vandal resistant handset and cord
Weather proof protection to IP66
Full keypad with memory, 0-9 buttons can be programmed as speed dial button
"LR" button for last number redial
"R" for flash recall
"M" for muting
Wall mounting, Easy for installation
Inductive coupler fitted as standard for hard of hearing, with LCD display
Phone line power supply or PoE (SIP-VoIP)
RJ45 port for SIP phone
CE, FCC, ROSH compliant
Outdoor Hotline Speed Dial Emergency Weatherproof Telephone for Tunnel
| Casing Material | Die cast aluminium body, cold rolled steel paceplate epoxy powder coated |
| Colors | yellow, other colors to special order |
| Handset Material | Cycoloy with stainless steel spiral cord |
| Keypad | Rubber Keypad |
| Temperature:Operating | Operating: -30°C to +65°C Storing: -40°C to +75°C |
| Weather Resistance | IP66-IP67 |
| Ringing Tone | Shrill warble tone 80 dBA @ 1 metre typical |
| Hook switch | Electronic/ magnetic with no visible moving parts |
| Push button | Vandal resistant stainless steel button |
| M.T.B.F. | Calculated to have an M.T.B.F. in excess of 60,000 hours using |
| Weight | Up to 5 kg depending on option |
| Package Materials | Pearl cotton, carton |
Outdoor Hotline Speed Dial Emergency Weatherproof Telephone for Tunnel
The phone is suitable for use in harsh environment characterized by: indoor & outdoor, Presence of dust & water ingress.for Tunnels, Mining, Marine, Construction sites, Blast furnace areas, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants, oil&Gas station, and related heavy duty industrial rough environment conditions, etc.
Outdoor Hotline Speed Dial Emergency Weatherproof Telephone for Tunnel
Outdoor Hotline Speed Dial Emergency Weatherproof Telephone for Tunnel
| unit size | 204*334*74(mm) |
| Carton size | 200*300*440(mm) |
| Package Materials | pearl cotton, carton |
| Gross Weight | 6KG |
| Net Weight | 5KG |
J&R is China based design and manufacturer of rugged communications equipment. Our telephones and systems work, and last, in environments where regular products wouldn't.
(All of our phone model avaliable for Analogue version,IP/SIP versio,GSM/3G version)
After well study your information,we sincerely hope to enter into partnership with your esteemed compnay.and we hope to serve you and cooperate with you for all of our product range in your market.
We could offer you all of our product range with ODM&OEM solution to meet your demands and requirement well.
and we will support you with the best product solution and costeffective solution to support you with the project requirement and marketing proposal.
