Home ProductsVandal Resistant Telephone

Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison

China J&R Technology Limited certification
China J&R Technology Limited certification
I'm Online Chat Now

Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison

Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison
Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison

Large Image :  Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison

Product Details:

Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR202-CB

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece
Price: negotiable
Packaging Details: J&R standard packing ,pearl cotton, carton
Delivery Time: 3-7 working days after payment
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 10000pcs per month
Detailed Product Description
Product Name: Hotline Emergency SIP Vandal Resistant Telephone For Public And Prison Casing Material: Robust Cold-rolled Steel Body
Handset Material: ABS Material Handset With Stainless Steel Spiral Cord Color: Gray, Red, Yellow
Operating Temperature: -30°C To +65°C Weather Resistance: IP65
Ringing Tone: 80-90db Hook Switch: Electronic / Magnetic With No Visible Moving Parts
Unit Size: 240 *100 *106(mm) Packaging Materials: Pearl Cotton, Carton
Net Weight: 2.7 Kg Application: Prisons, Jail, Parking Lots, Hospitals, Guard Stations, Police Stations, Bank Halls, ATM Machines
High Light:

vandal proof telephone

,

vandal proof intercom

Product Description

Hotline Emergency SIP Vandal Resistant Telephone for Public and Prison

This Telephone is housed in cold rolled steel box and manufactured to a high standard, it is offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times, resulting in a highly reliable product with a long MTBF.
Ideal for parking lots, prisons, railway/metro platforms,power plant,hospitals, police stations, ATM machines, stadiums, inside and outside building etc.



Main Features

Hotline Emergency SIP Vandal Resistant Telephone for Public and Prison



Features:
- Standard Analogue Phone, Avaliable for SIP Phone, GSM/3G Phone
- Telephone line powered for Analog Phone
- Robust housing, constructed of stainless steel
- Vandal resistant handset and armored cord
- Can be programmed remotely by tone phone or locally via keypad
- On wall mounting, simple installation
- Weather proof protection up to IP65
- Impact, shock, fall and vibration proof,able to perform in difficult environments
- Inductive coupler fitted as standard for hard of hearing
- CE, FCC, RoHS, ISO9001 compliant

Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 0Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 1

Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 2

Specification

Hotline Emergency SIP Vandal Resistant Telephone for Public and Prison

TECHNICAL SPECIFICATION:
Operating Temperatures: -40°C to + 70°C
Relative humidity high: 93% R.H at 40°C (non condensing)
Casing Material: Heavy Duty aluminium (salt & corrosion resistant)
Illuminated LCD Display: for status notifications and instructions
Flashing Light: ideal for noisy areas where a ring may not be heard, or for easy location inside dark tunnels etc
Excellent Sound Quality: STI approved to 0.9 (Excellent Sound)
Ringing volume: 80 dB(A) in 1m distance
Power Supply: 24V DC input, or Power over Ethernet (PoE).
Connection: RJ45 Ethernet socket through IP67 plug connector.
Quality of Service (QoS): ensuring optimal delivery of voice
Type of Service (ToS): high throughput and reliability (RFC3168)
ISDN gateway compliance: connect any SIP compliant VoIP/ISDN gateway to call to-and receive-calls from ISDN
SIP (Session Initiation Protocol) RFC3261
Inbuilt redundancy: able to make diversion calls to 2nd PBX
TR069 (Technical Report 069): for advanced status monitoring and control
Configuration: web interface or server based configuration file. Static IP address provisioning or DHCP. Mass configuration available.
Keypad Option: available without a keypad (autodial-on-handset-lift),used to initiate a PABX Hotline or wait for reply.
Remote Management: Available with remote management software,to simplify installation and cut maintenance costs.

Analogue Version

Power Supply

From the analogue telephone network

Supply Voltage

24 VDC to 65 VDC

Supply Current

20 mA DC to 100 mA DC

Ringer Volume

- 80dB(A) at a distance of 1 m

- 110dB(A) at a distance of 1 m (for external horn speaker)

Dialing Method

DTMF mode in accordance with ITU-T recommendation Q.23.

SIP Version

Power Supply

PoE or 12V DC

Power Consumption

-Idle:1.5W
-Active:1.8W

SIP Protocol

SIP 2.0 (RFC3261)

Support Codec

G.711 A/U, G.722 8000/16000, G.723, G.729

Communication Type

Full duplex

Ringer volume

- 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)

3G Version

Power Supply

12V DC

Power Consumption

-Idle:0.3W

-Active: 1.5W

Communication Type

Full duplex

Ringer volume

90~95dB(A) at a distance of 1 m

Program Method

Remote programming by SMS

Frequency

A version:
- Dual-Band WCDMA/HSDPA 850/1900MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
E version:
- Dual-Band UMTS/HSDPA 900/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
J version:
- Dual-Band UMTS/HSDPA 850(800)/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

Ambient conditions

Protection type

IP 66 as per EN60529

Operating temperature

-25°C to +70°C

Storage temperature

-25°C to +85°C



Application

Hotline Emergency SIP Vandal Resistant Telephone for Public and Prison



This vandal resistant telephone is Ideal for Railway applications, Marine applications, Tunnels. Underground Mining, Firefighter, Industrial, Prisons, Jail, Parking lots, Hospitals, Guard Stations, Police stations, Bank halls, ATM machines, Stadiums, inside and outside building etc.



Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 3





Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 4Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 5



Certifications

Hotline Emergency SIP Vandal Proof Telephone Cold Rolled Steel Body For Public / Prison 6

Our Company





J&R is one of the most professional manufacturers of emergency telephones, industrial telephones, Explosion-proof Telephones, and public telephones in Asia. The successful cooperation with thousands of customers all over the world and the supports to hundreds of projects have made us a reliable and popular supplier of industrial phones and phone accessories. Our main products include weatherproof phones, Explosion proof telephone, prison phones, emergency phones, elevator phones , acoustic phone booths and telephone kits as well.



As a reliable supplier of different kinds of industrial telephones, we have been sharing the equipments and systems with different customers and users all over the world. The professional service and excellent quality made us enjoy the reputation over more than 80 countries, including USA, China, Thailand, Malaysia, Turkey, Israel, Greece, Spain, France, UK, Denmark, South Africa, Australia, Mexico, Colombia, Chile etc.







Dedication and profession have been our pursuing goal during any procedures of our production, not only in developing and quality controlling, but also in marketing and after sales. We serve any single potential customer with special individual solutions and systems.

Choose J&R technology, choose reliable talks.

FAQ

Hotline Emergency SIP Vandal Resistant Telephone for Public and Prison



Q: Do You Have Any MOQ Limit?
A: Low MOQ, 1pc Is Available

Q: Can I Have A Sample Order ?
A: Yes, We Welcome Sample Order To Test And Check Quality.Mixed Samples Are Acceptable.

Q: What About The Lead Time?
A: Normally Within 2-5 Working Days. We Have Materials In Stock For Most Of Hot Selling Products.And Mass Production Time Needs 2-4 Weeks For Order Quantity More Than 100 Units.

Q: What's the quality standard of your products?
A: CE, FCC, RoHS, ISO9001:2015 certification approved. All materials are in high grade and new. With the strict quality, every phone be thoroughly tested before leaving the factory.

Q: Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q: Can you produce a product in a color of my choosing?
A: Yes, we can manufacture products in different colors, however there may be minimum quantities or surcharges applicable.

Q: Do you provide an installation service?
A: No, we do not install products, but they are very straightforward to install, please kindly contact us if unsure.

Q: When can I receive your quotation?
A: Once learn your detail requirements.

Q: How can I pay you?
A: Many convenient methods for choose: Paypal, T/T, L/C.
