Public Hearing Aid Telephone IP67 Outdoor Hands Free Emergency Telephones

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, IP67, ISO9001:2015
Model Number: JR104-SC
Minimum Order Quantity: 1 set
Price: Reconsideration
Packaging Details: pearl cotton, carton
Delivery Time: 3-7 working days
Payment Terms: L/C, T/T
Supply Ability: 3000 sets per month
Detail Information
Material: Aluminum Alloy Weather Resistant: IP67
Color: Yellow, Blue, Red, Orange (or Optional) Version: Analogue, SIP/VoIP, GSM/3G
Installation: Wall/ Pillar Mounting Warranty: 2 Years
Net Weight: 7 KG Hearing-Aid: YES
Vandal Resistant: Yes
High Light:

weather resistant telephone

,

weatherproof telephone box


Product Description

Public Hearing-Aid Telephone,IP67 Outdoor Hands free Emergency Telephones



This weatherproof telephone is fully contained within a corrosion resistant cast aluminium weatherproof case with Hearing-Aid  funiction and IP67 phone housing providing complete protection against dust and moisture ingress, resulting in a highly reliable product with a long MTBF.



APPLICATION:

This weatherproof telephone is idead for Tunnels, Mining, Marine, Underground, Metro stations, Railway platform, Highway side, Hotels, Parking lots, Steel Plants, Chemical plants, Power plants and relatedheavy duty industrial application, etc. which require very reliable telephony under adverse conditions.


Main Features:
- Standard Analogue phone, or SIP phone, or GSM/3G phone
- Aluminum alloy die-casting body
- Vandal resistant stainless steel button


- Weather proof protection to IP67
- Programmed for speed dial

- With Hearing-Aid
- Wall/ Pillar mounting, simple installation


- Phone line powered (Analogue)
- External power supply or PoE (SIP/VoIP)

- DC 24V powered (GSM/3G)
- RJ45 port for SIP phone


- Inductive coupler fitted as standard for hard of hearing
- CE, FCC, ISO9001, RoHS compliant




Technical Parameters



Ambient conditions
Protection type IP 66 as per EN60529
Operating temperature -40°C to +70°C
Storage temperature -45°C to +85°C




Analogue Version
Power Supply   From the analogue telephone network
Supply Voltage   24 VDC to 65 VDC
Supply Current   20 mA DC to 100 mA DC
Ringer Volume   - 80dB(A) at a distance of 1 m
  - 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method   DTMF mode in accordance with ITU-T recommendation Q.23.



SIP Version
Power Supply   PoE or 12V DC
Power Consumption   -Idle:1.5W
  -Active:1.8W
SIP Protocol   SIP 2.0 (RFC3261)
Support Codec   G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type   Full duplex
Ringer volume   - 90~95dB(A) at a distance of 1 m
  - 110dB(A) at a distance of 1 m (for external horn speaker)




Package

Unit size: 334*204*74(mm)
Carton size:200*300*440( mm )
Packaging materials: pearl cotton, carton
Net weight: 6KG
Gross weight: 7KG
