Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital

China J&R Technology Limited certification
China J&R Technology Limited certification
I'm Online Chat Now

Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital

Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital
Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital

Large Image :  Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital

Product Details:
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE,FCC,IP67
Model Number: JR303-SC
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiable
Packaging Details: Standard J&R packing
Delivery Time: 3-7 working days
Payment Terms: L/C, T/T, Western Union,paypal
Supply Ability: 1000pcs per week
Detailed Product Description
Version: Analogue/SIP/GSM Power Supply: Telephone Line Powered Or DC12V Powered
Ringing Volume: 80-90dB Main Chip: Broadcom
Mounting: Wall Mounting Or Flush Mounting Material: SUS/Cold-rolled Steel
Application: Inmate,bank,school,jail,prison,elevator Operating Temperature: -40°C To +70°C
G.W: 4.5KGS Warranty: 2 Years
SIP Protocol: SIP 2.0 (RFC3261) Protection Type: IP 66 As Per EN60529
High Light:

lift emergency phone

,

lift intercom phone

Product Description

Public Hospital Intercom Elevator Emergency Telephone Handsfree Call Point

Housed in stainless steel box with stainless steel faceplate and manufactured to a high standard, This VoIP emergency call box offers increased resistance to vandalism, and ensure that the primary function of communications is maintained reliable at all times.
Voice over Internet Protocol (VoIP) telephone requires a simple network connection and are compatible with most SIP-based IP-PBX servers to integrate into your existing network infrastructure.
For connection to a VoIP enable network, this emergency call box offer direct connection to LAN or WAN via RJ45 connector, including Power-Over-Ethernet (PoE) as standard. This VoIP emergency call box also offers a wealth of additional features, and can be configured by web browser


Main Features

Public Hospital Intercom Elevator Emergency Telephone Handsfree Call Point

Features:
- Standard SIP/VoIP phone
- Robust housing, constructed of stainless steel
- Vandal resistant metal button
- Hands free operation
- Flush mounting, simple installation
- Weather proof protection: IP55-IP65
- 12V DC input or Power over Ethernet (PoE)
- RJ45 Ethernet socket through IP67 plug connector
- Compatible with standard SIP protocol, independently accessible to VOIP phone system
(Asterisk, Elastix, Grandstream, Cisco, Yeastar etc. mainstream IP-PBX)
- With tamper-resistant, Conformal-coated PCBA
- Inductive Coupler Fitted as Standard for Hard of Hearing
- 4 X Tamper proof screws for mounting
- CE, FCC, ISO9001, RoHS compliant


Specification

Public Hospital Intercom Elevator Emergency Telephone Handsfree Call Point

TECHNICAL SPECIFICATION:
Operating Temperatures: -40°C to + 70°C
Relative humidity high: 93% R.H at 40°C (non condensing)
Casing Material: Heavy Duty aluminium (salt & corrosion resistant)
Illuminated LCD Display: for status notifications and instructions
Flashing Light: ideal for noisy areas where a ring may not be heard, or for easy location inside dark tunnels etc
Excellent Sound Quality: STI approved to 0.9 (Excellent Sound)
Ringing volume: 80 dB(A) in 1m distance
Power Supply: 24V DC input, or Power over Ethernet (PoE).
Connection: RJ45 Ethernet socket through IP67 plug connector.
Quality of Service (QoS): ensuring optimal delivery of voice
Type of Service (ToS): high throughput and reliability (RFC3168)
ISDN gateway compliance: connect any SIP compliant VoIP/ISDN gateway to call to-and receive-calls from ISDN
SIP (Session Initiation Protocol) RFC3261
Inbuilt redundancy: able to make diversion calls to 2nd PBX
TR069 (Technical Report 069): for advanced status monitoring and control
Configuration: web interface or server based configuration file. Static IP address provisioning or DHCP. Mass configuration available.
Keypad Option: available without a keypad (autodial-on-handset-lift),used to initiate a PABX Hotline or wait for reply.
Remote Management: Available with remote management software,to simplify installation and cut maintenance costs.

Analogue Version
Power Supply
From the analogue telephone network
Supply Voltage
24 VDC to 65 VDC
Supply Current
20 mA DC to 100 mA DC
Ringer Volume
- 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method
DTMF mode in accordance with ITU-T recommendation Q.23.
SIP Version
Power Supply
PoE or 12V DC
Power Consumption
-Idle:1.5W
-Active:1.8W
SIP Protocol
SIP 2.0 (RFC3261)
Support Codec
G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type
Full duplex
Ringer volume
- 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
3G Version
Power Supply
12V DC
Power Consumption
-Idle:0.3W
-Active: 1.5W
Communication Type
Full duplex
Ringer volume
90~95dB(A) at a distance of 1 m
Program Method
Remote programming by SMS
Frequency
A version:
- Dual-Band WCDMA/HSDPA 850/1900MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
E version:
- Dual-Band UMTS/HSDPA 900/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
J version:
- Dual-Band UMTS/HSDPA 850(800)/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
Ambient conditions
Protection type
IP 66 as per EN60529
Operating temperature
-25°C to +70°C
Storage temperature
-25°C to +85°C

Application

Public Hospital Intercom Elevator Emergency Telephone Handsfree Call Point

This clean room telephone is for Clean room, Sterile areas, Elevators/Lifts, Parking lots, Prisons, Railway/Metro platforms, Hospitals, Police stations, ATM machines, Stadiums, Campus, Shopping malls, Doors, Hotels, outside building etc

Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital 0
Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital 1

Certifications


Public Hospital Intercom Elevator Emergency Telephone Handsfree Call Point

Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital 2
Our Company


Public Hospital Intercom Elevator Emergency Telephone Handsfree Call Point



J&R is one of the most professional manufacturers of emergency telephones, industrial telephones, Explosion-proof Telephones, and public telephones in Asia. The successful cooperation with thousands of customers all over the world and the supports to hundreds of projects have made us a reliable and popular supplier of industrial phones and phone accessories. Our main products include weatherproof phones, Explosion proof telephone, prison phones, emergency phones, elevator phones , acoustic phone booths and telephone kits as well.



As a reliable supplier of different kinds of industrial telephones, we have been sharing the equipments and systems with different customers and users all over the world. The professional service and excellent quality made us enjoy the reputation over more than 80 countries, including USA, China, Thailand, Malaysia, Turkey, Israel, Greece, Spain, France, UK, Denmark, South Africa, Australia, Mexico, Colombia, Chile etc.

Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital 3
Intercom Elevator Emergency Phone Handsfree Call Point For Public / Hospital 4



Dedication and profession have been our pursuing goal during any procedures of our production, not only in developing and quality controlling, but also in marketing and after sales. We serve any single potential customer with special individual solutions and systems.

Choose J&R technology, choose reliable talks.

FAQ

SIP Public Hospital Intercom Handsfree Call Point Vandal Resistant Telephone

Q: Do You Have Any MOQ Limit?
A: Low MOQ, 1pc Is Available

Q: Can I Have A Sample Order ?
A: Yes, We Welcome Sample Order To Test And Check Quality.Mixed Samples Are Acceptable.

Q: What About The Lead Time?
A: Normally Within 2-5 Working Days. We Have Materials In Stock For Most Of Hot Selling Products.And Mass Production Time Needs 2-4 Weeks For Order Quantity More Than 100 Units.

Q: What's the quality standard of your products?
A: CE, FCC, RoHS, ISO9001:2015 certification approved. All materials are in high grade and new. With the strict quality, every phone be thoroughly tested before leaving the factory.

Q: Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q: Can you produce a product in a color of my choosing?
A: Yes, we can manufacture products in different colors, however there may be minimum quantities or surcharges applicable.

Q: Do you provide an installation service?
A: No, we do not install products, but they are very straightforward to install, please kindly contact us if unsure.

Q: When can I receive your quotation?
A: Once learn your detail requirements.

Q: How can I pay you?
A: Many convenient methods for choose: Paypal, T/T, L/C
