Vandal-proof Industry Kiosk, Acoustic Telephone Booths, Sound-proof Kiosk with Door

Basic Information
Place of Origin: Shenzhen, China
Brand Name: J&R
Certification: CE, FCC, RoHS, ISO9001
Model Number: JR-TH-03
Minimum Order Quantity: 1 unit
Price: Reconsideration
Packaging Details: Pearl cotton, Wooden box
Delivery Time: 8-12 working days
Payment Terms: L/C, T/T
Supply Ability: 1000 units per month
Detail Information
Material: Robust Galvanised Metal Noise Attenuation: 38 DB (with Door)
Size: 1100*1100*2400 (mm) Application: Outdoors, Off-Shore & On-Shore
Packaging Materials: Pearl Cotton, Wooden Support Net Weight: 300 KG
Installation: Stand Alone Fire Resistant: Yes
Vandal Retardant: Yes
High Light:

soundproof phone booth


wall mounted telephone booth


Vandal Proof Acoustic Telephone Booths

Product Description

Vandal-proof Kiosk for Heavy Duty Industry, Acoustic Telephone Booths, Sound-proof Kiosk with Door


JR-TH-03 is designed for noisy internal or external installations, providing a weatherproof and quieter telephone area.


Manufactured in robust galvanised metal. Internally the three sides of the booth are pre-lined with 50mm non-combustible, non-hygroscopic acoustic insulation. This is held in place by galvanised perforated panels. An acoustic slab is place inside the roof cavity for further insulation. And telephone will be fitted to the inner back panel of the booth.


Two vandal-proof windows allow a natural light source. And the telephone booth with fancy looking and inside lamp will provide a quiet and safety communication environment day and night.




- Standalone booth

- Robust metal construction

- Durable, Galvanized Plate body

- Contain an inside lamp


- Excellent low temperatures impact properties

- Completely maintenance free and corrosion resistant, impervious to chemical attack

- Noise reduction with door up to 38dB

- Noise reduction without door up to 25dB


- Fancy looking and modern

- Weatherproof, can be used outdoors, and suitable for harsh environment

- Optional colors and dimension available upon request

- Fire Retardant, UV Resistan, and Vandalism-proof

- Standalone, easy fixing system




  • Dimensions – H2400mm *W1100mm *D1100mm
  • Weight - Approx 300 KG
  • Standard Colour - Silver gray, Others to order
  • Body Material: Robust galvanised metal body
  • Acoustic Insulation - 50mm Tissue faced non hygroscopic Rockwool
  • Window - vandal-proof tempered glass

Each Acoustic Booth can be fitted with a JR telephone suited for specific needs and requirements, and equipped with:
• LED Strobe Light
• Industrial speaker/ringer, speaker or ringer (up to 110 dB)



Product Name Acoustic Telephone Booth
Model No. JR-PH-03
Materials Robust Galvanised Metal
Size 1100*1100*2400 (mm)
Application Heavy Industries, Refi neries, Airport, Oil&Gas plants, Factories, Chemical plants, Bulk loading stations, Mines, Drilling rigs, Steel mills, Off shore platforms, Any high noise industrial location and more.



1. ODM & OEM products or solutions

2. Sample order is greatly welcomed.

3. We will reply your inquiry within 12 hours

4. Update the productive process and show the packing details

5. After delivered the goods, we will track the products for you once every two days, until you get the products. When you got the products, if there is any further questions, welcome to contact us and we will solve the problems for you in time.




Unit size: 1100*1100*2400 (mm)

Wooden support size: 650*350*830 (mm)

Packaging materials: Pearl cotton, Wooden support

Net weight: 300 KG

Gross weight: 310 KG
